MAINTENANCE
70
10.1 POWER SUPPLY CABLE CONNECTIONS
Wire Cabin NT High seat
CE equipment
High seat
CE Comfort
1 GND GND +24VDC
2 GND GND +24VDC
3 Heater remote (+) Not used +24VDC
4 Emergency stop (-) Emergency stop (-) GND
5 +24VDC +24VDC GND
6 +24VDC +24VDC GND
7 +24VDC +24VDC Not used
8 +24VDC Not used Truck rpm increase
9 GND GND Truck rpm decrease
10 GND Not used Supply for rpm and motor start /
stop -switches
11 Truck rpm (+) CE boom height
warning (+)
Motor start
12 Truck rpm (-) CE Stabilizers out
warning (+)
Motor stop
13 CE boom / cabin
height warning (+)
Not used
14 CE Stabilizers out
warning (+)
Optional switch (+)
15 Not used Emergency stop (-)
16 Not used CE boom height warning (+)
17 Not used +24VDC for CE sensors
18 Not used CE Stabilizers out warning (+)
Recommended
external fuse
40A 30A 30A
Last wire in supply cable is yellow-green!
