GETTING TO KNOW YOUR KESTREL
BACK
DATA TRANSFER
PORT
SERIAL NUMBER
AA BATTERY (1)
(Lithium recommended)
LANYARD
ATTACHMENT
PRESSURE
SENSOR
FRONT
OPTIONS/EXIT
POWER
BACKLIGHT
SCROLL/ADJUST
TEMPERATURE
SENSOR
REPLACEABLE
IMPELLER
SELECT
BATTERY DOOR LATCH
HUMIDITY SENSOR
BATTERY DOOR
IMPELLER COVER
CAPTURE
SUNLIGHT
READABLE
DISPL
AY
BUTTONS
Button Name Function
POWER Turns Kestrel on and o. Press for on, hold for two seconds to turn o.
OPTIONS/ EXIT Enter the main Options menu or exit a menu.
SELECT Access Settings on any measurement screen or select a menu option to enter its
submenu or conrm a task.
UP/DOWN Scroll up and down through measurement screens or menus. Adjust values when
entering text in name menus.
LEFT/RIGHT Scroll options left and right. Adjust values in combo menus and setting sub-
menus.
CAPTURE In Weather Mode, manually capture all environmental values. In Ballistics mode,
turns on and o continuous wind capture.
BACKLIGHT Turn backlight on or o. (Also turns o automatically after one minute.)
