APPENDICE B: Midi Implementation
NOTE ON 9nHkkvvn(0-0FH) midichannel,kk(01H-7FH)=NOTEON
  vv=velocity(01H-7FH)(vv=0meansNOTEOFF)
NOTE OFF  8nHkkvvn(0-0FH) midichannel,kk(01H-7FH)=NOTEOFF
  9nHkk00Hvv=don’tcareifcommand8nH
PITCH BEND EnHblbh PitchBendasspecifiedbybl(low)

bh(high),bl=(00H-7FH),bh=(00H-7FH)14bitresolution.
  Maximumswingis+/-1tone(default).
  (CanbechangedusingRPN0000H)
  Centerpositionisbl=00Hbh=40H
  Min.bl=00Hbh=00H,Max.bl=7FHbh=7FH
PROGRAM CHANGE CnHppProgramchange.Ifn=09HDrumsetchange.
  Refertovoicesordrumsetlist.
CHANNEL AFTERTOUCH DnHvvvv=pressurevalue(00H-7FH).
  seeSystemexcl.listforAftertoucheffectsetting
CONTROL 00H  BnH00Hcc Bankselect.Seevoiceslistfordetails.
CONTROL 01H  BnH01Hcc Modulationwheel.Rate,Assignmentcanbesetusing
  Systemexcl.
CONTROL 05H  BnH05Hcc Portamentotime
CONTROL 06H  BnH06Hcc DataEntry.ProvidesdatatoRPNNRPN
CONTROL 07H  BnH07Hcc Volume
CONTROL 0AH  BnH0AHcc Pan.(Default40H)
CONTROL 0BH  BnH0BHcc Expression.(Default7FH)
CONTROL 14H  BnH14Hcc DrawBar16’,cc=amount
CONTROL 15H BnH15Hcc DrawBar8’,cc=amount
CONTROL 16H BnH16Hcc DrawBar5‘1/3,cc=amount
CONTROL 17H BnH17Hcc DrawBar4’,cc=amount
CONTROL 18H BnH18Hcc DrawBar2’2/3,cc=amount
CONTROL 19H BnH19Hcc DrawBar2’,cc=amount
CONTROL 1AH  BnH1AHcc DrawBar1’3/5,cc=amount
CONTROL 1BH  BnH1BHcc DrawBar1’,cc=amount
CONTROL 1CH BnH1CHcc DrawBarPerc4’,cc=amount
CONTROL 1DH BnH1DHcc DrawBarPerc2’2/3,cc=amount
CONTROL 1EH  BnH1EHcc Rotorcc=00Hoff,cc=40Hslow,cc=7FHfast
  00H=rotorOFF(returntodefaultchorus)
CONTROL 40H BnH40Hcc Sustain.(Dumperpedal)On=7FH,Off=00H
CONTROL 41H BnH41Hcc Portamento.On/OffOn=7FH,Off=00H
CONTROL 42H BnH42Hcc SostenutopedalOn=7FH,Off=00H
CONTROL 43H BnH43Hcc SoftpedalOn=7FH,Off=00H
CONTROL 54H  BnH54Hcc Wha-WhaOn/OffOn=7FHOff=00h
CONTROL 55H BnH55Hcc Wha-WhaAmountcc=00H-7FH.
CONTROL 5BH  BnH5BHcc Auxiliarychannel1Reverbsendvv=00H-7FH
CONTROL 5DH  BnH5DHcc Auxiliarychannel2Effectssendvv=00H-7FH 
  (chorus,delay,distorsor)
CONTROL 77H BnH77H00H ResetallNRPN(seenote1).
CONTROL 78H  BnH78H00H Allsoundoff.(Abrutstopofsoundonchanneln)
CONTROL 79H BnH79H00H Resetallcontrollers
CONTROL 7BH  BnH7BH00H AllNotesOff
CONTROL 7EH  BnH7EH00H Monoon
CONTROL 7FH BnH7FH00H PolyOn(default)
