EnH Bl bh Pitch bend as specified by bh/bl (14 bits)
Maximum swing is +/- 1 tone (power-up). Can be changed
Using “pitch bend sensitivity”. Center position is 00H 40H.
PROGRAM
CHANGE
CnH pp Program (patch) change. Specific action on channel 10 (n=9):
select drumset. Refer to sounds / drumse list. Drumsets can
be assigned to other channels (see SYSEX MIDI channel to
part assign and part to rhythm allocation)
CHANNEL
A. TOUCH
DnH vv Vv pressure value. Effect set using Sys. Ex. 40H 2nH 20H-26H
FFH Reset to power-up condition
CTRL 00 BnH 00H cc Bank select
CTRL 01 BnH 01H cc Modulation Wheel. Rate and maximum depht can be set using
SYSEX
CTRL 05 BnH 05H cc Portamento Time
CTRL 06 BnH 06H cc Data entry : provides data to RPN and NRPN
CTRL 07 BnH 07H cc Volume (default=100)
CTRL 10 BnH 0AH cc Pan (default=64 center)
CTRL 11 BnH 0BH cc Expression (default=127)
CTRL 64 BnH 40H cc Sustain (Damper) pedal
CTRL 65 BnH 41H cc Portamento ON/OFF
CTRL 66 BnH 42H cc Sostenuto pedal
CTRL 67 BnH 43H cc Soft pedal
CTRL 84 BnH 54H cc Wha-Wha ON/OFF
CTRL 85 BnH 55H cc Wha-Wha Amount
CTRL 91 BnH 5BH vv Auxiliary channel 1 send level vv=00H to 7FH
CTRL 93 BnH 5D vv Auxiliary channel 2 send level vv=00H to 7FH
CTRL 119 BnH 77H 00H Reset all nrpn
CTRL 120 BnH 78H 00H All sound off (abrupt stop of sound on channel n)
CTRL 121 BnH 79H 00H Reset all controllers
CTRL 123 BnH 7BH 00H All notes off
CTRL 126 BnH 7EH 00H Mono on
CTRL 127 BnH 7FH 00H Poly on (default power-up)
RPN 0000H BnH 65H 00H 64H 00H 06H vv Pitch bend sensitivity in semitones (default=2)
RPN 0001H BnH 65H 00H 64H 01H 06H vv Fine tuning in cents (vv=00 – 100, vv=40H 0, vv=7FH+100
RPN 0002H BnH 65H 00H 64H 02H 06H vv Coarse tuning in half-tones (vv=00-64, vv=40H 0, vv=7FH+ 64
