110
EXCLUSIVE MESSAGES
PARAMETER GENERAL FORM: F0H 26H 7BH Code Data_1 . . Data_n F7H
Effect type
Reverb type F0H 26H 7BH 00H Rev type F7H Rev type = 00H – 13H Reverb OFF = 7FH
Reverb level F0H 26H 7BH 02H Level F7H Rev Level = 00H – 10H
Chorus type F0H 26H 7BH 01H Chorus type F7H Chorus type = 00H – 0BH Chorus OFF = 7FH
Delay type F0H 26H 7BH 06H Delay type F7H Delay type = 00H – 0BH Delay OFF = 7FH
Distorsor t
yp
e
F0H 26H 7BH 11H Dist type F7H Distorsor type = 00H – 0BH Distorsor OFF = 7FH
TYPE EFFECTS CHANNEL ASSIGN: F0H 26H 7BH 00H Channel Effect_Type F7H
Channel: 00H – 0FH Keyboard
Channel: 10H – 1FH GM Song Play mode
Effect type
0
No effects
3
Chorus
5
Delay + Chorus
7
Distorsor + Delay
1
Leslie
4
Delay
6
Distorsor + Chorus
8
Distorsor + Delay + Chorus
2
Distorsor
CHORUS PARAMETERS
F0H 26H 7BH Delay_parameter 00H Value F7H
Delay parameter Value
2BH
Feedback
0 – 7FH
2CH
Filter
0 – 68H
DELAY PARAMETERS
F0H 26H 7BH Chorus_Parameter 00H Value F7H
Chorus parameter Value
3BH
Volume
0 – 7FH
74H Delay
0 – 7FH
75H Feedback
0 – 7FH
76H Rate
0 – 7FH
77H Depth
0 – 7FH
DELAY PARAMETERS
F0H 26H 7BH Delay_parameter 00H Value F7H
Delay parameter Value
2BH
Feedback
0 – 7FH
2CH
Filter
0 – 68H
DELAY TIME: F0H 26H 7BH 29H 00H Time_center (0 – 7FH) Time_left (0 – 7FH) Time_right (0 – 7FH)
DELAY VOLUME: F0H 26H 7BH 2AH 00H Vol_center (0 – 7FH) Vol_left (0 – 7FH) Vol_right (0 – 7FH)
DISTORSOR PARAMETER
F0H 26H 7BH Distorsor_parameter 00H Value F7H
Distorsor parameter Value
22H Volume
00H - 7FH
25H Tone
10H - 66H
26H Resonance
18H - 7FH
MICROPHONE PARAMETER
F0H 26H 7BH Micro_parameter 00H Value F7H
Microphone parameter Value
50H On 7FH
50H Off 00H
51H Right Volume
00H – 7FH
52H Left Volume
00H – 7FH
53H Right Pan
00H – 7FH
54H Left Pan
00H – 7FH
55H Right Echo
00H – 7FH
56H Left Echo
00H – 7FH
57H Right Reverb
00H – 7FH
58H Left Reverb
00H – 7FH
