Before assembling or using the exercise cycle , please read the following instructions carefully. They contain important
information for use and maintenance of the equipment as well as for your personal safety. Keep these instructions in a
safe place for maintenance purposes or for ordering spare parts.
ASSEMBLY INSTRUCTIONS
RISK! Instruct people using the equipment (in particular chil-
dren) on possible sources of danger during exercising.
RISK! While assembly of the product keep o children’s reach
(Choking hazard - contains small parts).
RISK! Heart rate monitoring systems can be imprecise. Exces-
sive training may lead to serious health damage or death. If you
feel giddy or weak, please stop the training immediately.
WARNING! The training device should be used only for its
intended purpose, i.e. for physical exercise by adult people.
WARNING! Any other use of the equipment is prohibited and
may be dangerous. The manufacturer cannot be held liable for
damage or injury caused by improper use of the equipment.
WARNING! Before beginning your program of training, study
the instructions for training carefully.
WARNING! All electric appliances emit electromagnetic radia-
tion when in operation. Please do not leave especially radiation-
intensive appliances (e.g. mobile telephones) directly next to
the cockpit or the electronic controlsystem as otherwise values
displayed might be distorted (e.g. pulse measurement.
Exercise has been designed in accordance with the latest
standards of safety. Any features which may have been a
possible cause of injury have been avoided or made as safe
as possible.
Incorrect repairs and structural modications (e.g. removal
or replacement of original parts) may endanger the safety
of the user.
Damaged components may endanger your safety or re-
duce the lifetime of the equipment. For this reason, worn
or damaged parts should be replaced immediately and the
equipment taken out of use until this has been done. Use
only original KETTLER spare parts.
If the equipment is in regular use, check all its components
thoroughly every 1 -2 months. Pay particular attention to
the tightness of bolts and nuts.This applies especially to the
securing bolts for saddle and handelbars.
To ensure that the safety level is kept to the highest possi-
blestandard, determined by its construction, this product
should be serviced regulary (once a year) by specialist
retailers.
Before beginning your program of exercise, consult your
doctor to ensure that you are t enough to use the equip-
ment. Base your program of exercise on the advice given by
your doctor. Incorrect or excessive exercise may damage
your health!
Any interference with parts of the product that are not
described within the manual may cause damage, or endan-
ger the person using this machine. Extensive repairs must
only be carried out by KETTLER service sta or qualied
personnel trained by KETTLER.
Our products are subject to a constant innovative quality
assurance. We reserve the right to perform technical modi-
cations.
In case of enquiry, please contact your KETTLER dealer.
In choosing the location of the apparatus, ensure a sucient
safety distance from any obstacles. The apparatus must not
be mounted in the immediate vicinity of main passageways
(paths, doorways, corridors). The safety distance surroun-
ding must extend at least 1 meter further than the practice
area.
The training machine must be positioned on a horizontal,
stable surface.
For a comfortable training position please adjust the hand-
lebar andsaddle position to your body height.
When mounting the product please take the recommended-
torque information into account (M = xx Nm).
The exercise cycle complies with the DIN EN 20957-1/
EN 957-5, class HB. Accordingly, it is not suitable for high
accuracy.
This appliance can be used by children aged from 14 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concer-
ning use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by chil-
dren without supervision.
AVIOR M / HT1002-100
FOR YOUR SAFETY
HANDLING THE EQUIPMENT
INSTRUCTIONS FOR ASSEMBLY
Ensure that you have received all the parts required (see
check list) and that they are undamaged. Should you have
any cause for complaint, please contact your KETTLER
dealer.
Before assembling the equipment, study the drawings care-
fully and carry out the operations in the order shown by the
diagrams. The correct sequence is given in capital letters.
The equipment must be assembled with due care by an adult
person. If in doubt call upon the help of a second person, if
possible technically talented.
Please note that there is always a danger of injury when
working with tools or doing manual work. Therefore please
be careful when assembling this machine.
The fastening material required for each assembly step
is shown in the diagram inset. Use the fastening material
exactly as instructed.
Bolt all the parts together loosely at rst, and check that
they have been assembled correctly. Tighten the locknuts
by hand until resistance is felt, then use spanner to nally
tighten nuts completely against resistance (locking device).
Then check that all screw connections have been tightened
rmly. Attention: once locknuts have been unscrewed they
no longer function correctly (the locking device is de-
stroyed), and must be replaced.
For technical reasons, we reserve the right to carry out
preliminary assembly work (e.g. addition of tubing plugs).
LIST OF SPARE PARTS PAGE 24-25
When ordering spare parts, always state the full article number,
spare-partnumber, the quantity required and the S/N of the
product (see handling). Example order: Art.no. HT10002-.... /
spare-part no. 68009040 / 1 pieces / S/N ....................
Waste Disposal
KETTLER products are recyclable. At the end of its
useful life please dispose
of this article correctly and safely (local refuse sites).
Before using the equipment for exercise, check carefully to
ensure that it has been correctly assembled.
Before beginning your rst training session, familiarize your-
self thoroughl with all the functions and settings of the unit.
The machine is designed for use by adults and children
should not be allowed to play with it. Children at play behave
unpredictably and dangerous situations may occur for
which the manufacturer cannot be held liable. If, in spite
of this, children are allowed to use the equipment, ensure
that they are instructed in its proper use and supervised
accordingly.
A slight production of noise at the bearing of the centrif-
ugal mass is due to the construction and has no negative
eect upon operation. Possibly occurring noise during
reverse pedalling result from engineering and are absolutely
safe.
The exercise cycle has a magnetic brake system.
The equipment is dependent of revolutions per minute.
Please ensure that liquids or perspiration never enter the
machine or the electronics.
Before use, always check all screws and plug-in connections
as well as respective safety devices t correctly.
Always wear suitable shoes when using.
Nobody may be in the moving range of a training person
during training.
RISK! Ensure that your working area is free of possible sources
of danger, for example don’t leave any tools lying around. Always
dispose packaging
material in such a way that it may not cause any danger. There is
always a risk of suocation if children play with plastic bags!
This manual can be downloaded from
www.kettlersport.com
ATTENTION! It is not recommended to use or store the appa-
ratus in a damp room as this may cause it to rust. Please ensure
that no part of the
machine comes in contact with liquids (drinks, perspiration etc.).
This may cause corrosion.
