Key Automation 900RAY2524 User Manual

9
EN
2 - PRODUCT OVERVIEW
2.1 - Description of the product
RAY gear motors are destined to be installed in systems for the
automation of gates with hinged doors.
RAY gear motors have been designed and constructed to be tted
onto hinged doors within the weight limits indicated in the technical
specications table.
The use of gear motors for applications which di󰀨er from those
indicated above is prohibited.
2.2 - Model and technical characteristics
3 - PRELIMINARY CHECKS
Before installing this product, verify and check the following steps:
- Check that the gate or door are suitable for automation
- The weight and size of the gate or door must be within the maxi-
mum permissible operating limits specied in Fig. 2
- Check the presence and strength of the security mechanical stops
of the gate or door
- Check that the mounting area of the product is not subject to ood-
ing
- Conditions of high acidity or salinity or proximity to heat sources
could cause malfunction of the product
- Extreme weather conditions (for example the presence of snow,
ice, high temperature range, high temperatures) may increase the
friction and therefore the force required for the handling and initial
starting point may be higher than under normal conditions.
- Check that the manual operation of gate or door is smooth and
friction-free and there is no risk of derailment of the same
- Check that the gate or door are in equilibrium and stationary if left
in any position
- Check that the power line to supply the product is equipped with
proper grounding safety and protected by a magnetothermal and
di󰀨erential security device
- Provide the power system with a disconnecting device with a gap
of contacts enabling full disconnection under the conditions dictated
by the overvoltage category III.
- Ensure that all materials used for the installation comply with cur-
rent regulations
* with optimized xing dimensions
Code Description
RAY2524 Gear motor for hinged doors with max length 3 m or max weight 500 Kg, 24 Vdc
RAY4024E Gear motor for hinged doors with max length 4 m or max weight 600 Kg with encoder, 24 Vdc
RAY40 Gear motor for hinged doors with max length 4 m or max weight 600 Kg, 230 Vac
RAY40110 Gear motor for hinged doors with max length 4 m or max weight 600 Kg, 110 Vac
RAY2224 Gear motor for hinged doors with max length 3 m or max weight 300 Kg, 24 Vdc
RAY4024R Gear motor for hinged doors with max length 4 m or max weight 500 Kg, 24 Vdc, reversible
RAY3024F Gear motor for hinged doors with max length 3 m or max weight 300 kg, 24 Vdc with encoder
TECHNICAL DATA
MODELS
RAY2524
RAY4024
RAY4024E
RAY40 RAY40110 RAY2224 RAY4024R RAY3024F
Speed 2,6 cm/s 1,5 cm/s 1,6 cm/s 1,6 cm/s 2,6 cm/s 3 cm/s 3,8 cm/s
Thrust force 1500 N 2000 N 2000 N 2000 N 1500 N 1000 N 1000 N
Working cycle 80% 80% 40% 40% 80% 80% 50%
Opening time at 90° 18-25* 20-25* 20-25* 25 sec 18-25* 15-20* 10-15*
Working stroke 415 mm 415 mm 415 mm 415 mm 415 mm 415 mm 415 mm
Control board 14AB 14AB2 CT202 CT202V120 CT202 24 14AB2 14AB2F
Power supply 24 Vdc 24 Vdc 230 Vac 110 Vac 24 Vdc 24 Vdc 24 Vdc
Absorption 3,5 A 5 A 1,2 A 2,2 A 3,5 A 5 A 5 A
Engine power 85 W 120 W 280 W 280 W 85 W 120 W 120 W
Capacitor - - 8 µF 20 µF - - -
Thermoprotection - - 150 °C 150 °C - - -
Integrated lights si si - - - si si
Degree of protection IP44 IP44 IP44 IP44 IP44 IP44 IP44
Dimensions (L - P - H)
844-100-104
mm
844-100-104
mm
844-100-104
mm
844-100-104
mm
844-100-104
mm
844-100-104
mm
844-100-104
mm
Weight 6 Kg 8 Kg 8 Kg 8 Kg 6 Kg 8 Kg 8 Kg
Operating temperature -20°+55°C -20°+55°C -20°+55°C -20°+55°C -20°+55°C -20°+55°C -20°+55°C
Noise emission level ≤ 70dB(A) ≤ 70dB(A) ≤ 70dB(A) ≤ 70dB(A) ≤ 70dB(A) ≤ 70dB(A) ≤ 70dB(A)
