22
EN
EOL
2. Friction on runners or rack (see motor current [A]).
EED
ELS
3. Check the travel time which has passed without tripping of the limit switches.
After eliminating the cause of the alarm, to delete all errors simply
Phototest fail outcome.
EPH
1. Check the photocell and the safety edge connections.
2. Check that the photocells and the safety edg are operating correctly.
Encoder encoder (only if encoder is present)
EEN
1. Check the encoder connections.
2. Check that the encoder are operating correctly.
opening
closure
automatic closure
stop during closure
stop during opening
open
closed
programmation During the programming phase
obstacle M1 Motor 1 obstacle detected
photo 1! Photocell 1 tripped
photo 2! Photocell 2 tripped
sensitive edge! Sensitive edge tripped
pedestrian opening Pedestrian opening in progress
automatic pedestrian closure
realignment
phototest error Phototest error detected
encoder error Encoder error detected
DISPLAY
Status display (--, OP, CL, SO, ecc..) Description of the control unit (--, OP, CL, SO, ecc..)
Maneuvers performed Counter displays alternating the thousands (without dots) and the units (with dots).
Motor current [A] Current absorbed by the motor
Press “UP“ to read the following parameters on display.
