courtesy light operation - operation after power failure - ashing
activation for maintenance - default - input lock with password -
receiver lock with password - stop contact.to change follow the in-
structions on the screen.
* After adjusting the parameter it is mandatory to control at
least two complete operations to allow the control unit to store
the motor stress throughout the stroke
4.17 - KUBE PRO / KUBE wireless module connection
Before carrying out any operation, power o the equipment.
Remove the plastic protection cover of the KUBE module connector.
Remove the plastic shells (FIG. 49) and insert the card in its special
input slot (FIG. 50).
Once removed from its container, handle the KUBE module
with extreme care.
Carefully check the position of the KUBE module on the control
unit connector (FIG. 50).
With the KUBE PRO and DYL programmers it is possible to change,
in addition to the parameters (TAB. 3), the following parameters:
opening speed* - slowing speed in opening* - closing speed* -
slowing speed in closing* - slowing extent in opening* - slowing ex-
tent in closing* - phototest - sensitive edge test - partial opening
extent - garage ventilation function extent - partial automatic closing
time - ventilation automatic closing time - ashing operation mode
- pre-ashing time - light intensity at end of movement - integrated
ATTENTION !
ATTENTION !
ATTENTION !
4.16 - Using the display programmer
To customise the programmer’s language, proceed as follows:
N.B.: When the display is turned on for the rst time, the user
will be prompted to select a language. Press ▲ or ▼ to select
the desired language and then conrm with V.
If no language is selected (press the X key), the control unit will
use the default language (ENGLISH) until the next power-on.
In normal mode, i.e. when the system is powered on normally
and the display programmer is connected, press X until the
wording “Key Automation” is displayed. In this way, you will
be able to view the following status messages:
OPTIONS
DISPLAY
LANGUAGE
SELECTION
CONFIRM
SCROLL UP
KEY AUTOMATION
SCROLL DOWN
CANCEL
EVENT DESCRIPTION
FLASHING INDICATION AND
CONTROL UNIT CONTROL LEDS
opening Door opening
ventilation opening Door opening for ventilation
closing Door closing
automatic closing Open door with timed closing active
stop in closing Door stopped in closing phase
stop in opening Door stopped in opening phase
open Door fully open without automatic closing
open in ventilation Door open in ventilation without automatic closing
closed Door fully closed
programming During the programming phase 2 fast ashes + pause + 1 ash
obstacle Detected motor obstacle 4 fast ashes + pause 3 times
photo! Photocell operation 2 fast ashes + pause 3 times
sensitive edge! Sensitive edge operation 5 fast ashes + pause 3 times
partial opening Partial opening in progress
partial automatic closing Partial door opening with active timed closing
ventilation automatic closing Open door in ventilation with active timed closing
FLASH/LED error FLASH and LED output overload 6 fast ashes + pause 3 times
phototest error Phototest error detected 3 fast ashes + pause 3 times
limit switch error! Limit switch/mechanical stop error detected 8 fast ashes + pause 3 times
memory error Memory error detected 10 fast ashes + pause 3 times
