Key Automation RAY Series User Manual

42
Fig. 15 IT - Sostituzione led
EN - Replacement of the leds
DE - Auswechseln der Led
ES - Sustitución de las luces led
FR - Remplacement des DEL
PT - Substituição led
PL - Wymiana diod led
2
1
IT - solo 24 Vdc
EN - only 24 Vdc
DE - nur 24 Vdc
ES - solo 24 Vdc
FR - seulement 24 Vdc
PT - só 24 Vdc
PL - tylko 24 Vdc
15a 15b
Fig. 13-14 IT - Connessioni elettriche
EN - Power connections
DE - Elektrische Anschlüsse
ES - Conexiones eléctricas
FR - Branchements électriques
PT - Conexões eléctricas
PL - Połączenia elektryczne
Fig. 13
Fig. 14a
Fig. 14b
Fig. 14c
24 Vdc 230 Vac / 110 Vac
Fig. 14d
RAY2224
Fig. 14c
M-
M+
M-
M+
LED
COM
RAY4024E
Fig. 14a
RAY2524
Fig. 14b
M-
M+
LED
COM
NEG
ENC
V+
MOTOR
MOTOR MOTOR
ENCODER LED
LED
RAY40
Fig. 14d
COM
L1 L2
MOTOR
