IV Series (Sensor) - IM_E
Dimensions
Sensor
IV-500C / IV-500CA / IV-500M / IV-500MA / IV-150M / IV-150MA / IV-2000M / IV-2000MA
Mounting
adapter
(102)
R50
R50
(108)
50
57.4
32.4
56
81.5
50
10.5 10.5
610.5
20.5
41
(Depth 6mm)
3-M3
52
0.4
Focusing position adjustment screw
(MF type only)
WD reference surface
45.5 25
58
20
4-M4
(Depth 6mm)
1/4-20UNC
(Depth 6mm)
Power I/O cable
OP-87440 (2m) / OP-87441 (5m) / OP-87442 (10m)
10000
5000
2000
φ6.7
45
φ15
120 5
150
5
180
5
Bracket
OP-87685
48.4
0.4 112.5
50
(99)
58
41
31.6
99
19.6
93
56
82.5
