Keyscan Technical Guide (PC109x - 04.12)
59
Supported Keypad Wiegand Outputs
Keyscan supports the following keypad PIN data Wiegand outputs:
• HID Wiegand with 4-bit word burst
• Indala unbuffered mode Wiegand with 8-bit word burst
• WSSKP-1 facility code 0 (zero) with 36-bit Keyscan Wiegand output
If using third party biometric devices connected to Keyscan CA or EC control board reader ports, do not use
reserved facility code 0 (zero).
Note
Reader formats reviewed in the table below apply to PROM version 4.03 or greater. The Keyscan 36-bit
format is proprietary.
Table 8 – Reader Configuration Jumper J3
Card Number Formats
• Standard – Facility Code 1 – 255 / Card Number 1 – 65535 unless noted otherwise
• Extended – Hexadecimal 1 – FFFFFFFFFFFF or Decimal 1 – 281474976710655 / Checked for Extended
Number
Ref
#
Reader Format Security
Level
Settings
Pins 6 - 1
Card Number
Format
Notes
A Keyscan 36-bit only High 0 0 0 0 0 0 Standard
B FIPS/TWIC – 75-bit output (48-
bit FASC-N, 25-bit expiration
date, 2 parity bits)
High 1 0 0 0 0 0 Extended
C HID Corporate 1000 - 35-bit
output
Medium 1 0 0 0 0 1 Extended
D MIFARE – CSN 32-bit output Low 1 0 0 0 1 0 Extended Only reads the Card
Serial Number sector
E MIFARE – Reverse CSN 32-bit
output
Low 1 0 0 0 1 1 Extended Only reads the Card
Serial Number sector
F MIFARE – 40-bit CSN (32-bit
CSN, 8-bit Checksum)
Low 1 0 0 1 0 0 Extended Only reads the Card
Serial Number sector
G 26 to 48 Pass-through Large
Card Format
Medium -
Low
1 1 1 1 1 1 Extended
H 26 to 48 Pass-through Large
Card Format (with first and last
parity bits dropped)
Medium -
Low
1 1 1 1 1 0 Extended
I University 1000 - 56-bit Medium 1 0 0 1 1 0 Extended Custom order only.
Facility code required
when ordering.
J MIFARE Reverse 40-bit (32-bits
reverse CSN + 8-bits checksum
= 40 bits
Low 1 0 0 1 0 1 Extended Only reads the Card
Serial Number sector
K MLF Indala Format = 16039 Medium 1 0 0 1 1 1 Extended Custom order only.
Letter required from
dealer.
