Keysight Technologies B1500A

Module 2
Basic Measurement
2-26
The Extended Setup dialog box allows the user to set the additional test setup parameters. In the Id-
Vd setup, the additional parameters are source voltage, maximum gate current, maximum substrate
current, integration time, hold time, and delay time.
