Service and Maintenance 1
Keysight E36200 Series Service Guide 51
21 Remove three screws from the IO board using a
T10 bit. Remove the IO board from the chassis.
22 Unsolder the binding post assembly from the IO
board. Replace the existing binding post
assembly with a new binding post assembly.
23 Perform the steps above in reverse order to reassamble back the instrument.
Step Instructions Visuals
