Verification and Adjustments 2
Keysight E36200 Series Service Guide 55
Test considerations
– Ensure that the calibration ambient temperature is stable and between 20 °C
and 30 °C.
– Ensure ambient relative humidity is less than 80%.
– Allow a 1-hour warm-up period before verification or calibration.
– Keep cables as short as possible, consistent with the impedance requirements.
– Performance verification and calibration procedure must be performed
through rear panel output.
Terminations
1 – 50 Ω BNC termination
N/A
2 – 50 Ω, ≥ 1/8 W resistor
Variable voltage
transformer or AC
source
Adjustable to highest rated input voltage range
Power: 500 VA
Keysight 6813B or equivalent
Resistors for low
range current
E36231/E36233A output: 300 Ω high power resistor, 5 W ARCOL HS100 300R F
E36232A/E36234A output: 1.2 kΩ power resistor, 5 W ARCOL HS75 1K2 F
Type Specification Recommended model
The tests should be performed by qualified personnel. During performance
verification tests, hazardous voltages may be present at the outputs of the
power supply.
Refer to the E36200 Series Programming Guide for more information on the SCPI
commands used in this chapter.
For E36233A and E36234A models, perform the verification test described below
for Output 1 and then repeat the test again for Output 2.
