2 Verification and Adjustments
72 Keysight E36200 Series Service Guide
7 Operate the electronic load in short (input short) mode. Record the current
reading, (I
short
), by dividing the voltage reading on the DMM by the resistance
of the current monitoring resistor.
8 Take the difference between the current readings in step 6 and step 7 is the
load regulation current (I
load
– I
short
). Record the calculated value in the “Test
Record Forms” on page 74. The difference of the readings during the
immediate change should be within the specification limits.
CCline regulation
1 Turn off the power supply using the AC line switch.
2 Connect the power supply output with a DMM, an electronic load, and a
current shunt. See “Recommended test equipment” on page 54 for details.
3 Connect the AC power cord of the power supply to the AC power source.
4 Turn on the power supply using the AC line switch.
5 Program the output voltage and output current as described in the test record
form under CC line regulation.
6 Operate the electronic load in constant voltage mode and set its voltage to the
power supply output value as described in Table 2-10.
Check that the front panel CC annunciator of the power supply remains lit. If it
turns to CV or UNREG, adjust the load so that the output current drops slightly
until the CC annunciator lights up.
Table 2-9 CC load regulation instrument settings
DUT settings E-load settings Load regulation
Model Voltage (V) Current (A) Mode Voltage (V) Lower limit Upper limit
E36231A /
E36233A
MAX 6.667 Voltage 30 –0.9167 mA 0.9167 mA
MAX 20 Voltage 10 –2.250 mA 2.250 mA
E36232A /
E36234A
MAX 3.333 Voltage 60 –0.5833 mA 0.5833 mA
MAX 10 Voltage 20 –1.250 mA 1.250 mA
