Verification and Adjustments 2
Keysight E36200 Series Service Guide 73
7 Adjust the AC power source to low line voltage limit (see Table 2-10). Record
the output current reading (I
lowline
) by dividing the voltage reading on the
DMM by the resistance of the current monitoring resistor.
8 Adjust the AC power source to high line voltage (see Table 2-10). Record the
current reading (I
highline
) again immediately by dividing the voltage reading on
the DMM by the resistance of the current monitoring resistor.
9 Take the difference between the DMM readings in step 7 and step 8 is the CC
line regulation (I
lowline
– I
highline
). Record the calculated value in the “Test
Record Forms” on page 74. The difference of the readings during the
immediate change should be within the specification limits.
Table 2-10 CCline regulation instrument settings
Model
DUT settings AC source settings E-load settings Line regulation
Voltage
(V)
Current
(A)
Low High Mode
Voltage
(V)
Lower limit Upper limit
Line
voltage
E36231A /
E36233A
MAX 6.667
90 VAC 132 VAC
Voltage 30 –0.9167 mA 0.9167 mA
100 VAC -
120 VAC
MAX 20 Voltage 10 –2.250 mA 2.250 mA
MAX 6.667
180 VAC 264 VAC
Voltage 30 –0.9167 mA 0.9167 mA
200 VAC -
240 VAC
MAX 20 Voltage 10 –2.250 mA 2.250 mA
E36232A /
E36234A
MAX 3.333
90 VAC 132 VAC
Voltage 60 –0.5833 mA 0.5833 mA
100 VAC -
120 VAC
MAX 10 Voltage 20 –1.250 mA 1.250 mA
MAX 3.333
180 VAC 264 VAC
Voltage 60 –0.5833 mA 0.5833 mA
200 VAC -
240 VAC
MAX 10 Voltage 20 –1.250 mA 1.250 mA
