Service and Maintenance 1
Keysight E36200 Series Service Guide 27
13 Detach the AC inlet connector from the PSU
module.
14 Detach the power PSU connector from the
mainboard.
15 Remove one screw from the rear chassis using a
T10 bit.
Step Instructions Visuals
To Next Page
