1 Service and Maintenance
26 Keysight E36200 Series Service Guide
NOTE: Perform step 10 and step 12 only if you have installed the optional GPIB interface (see “Removing/Installing the optional
GPIB interface” on page 20 for more details).
10 Remove one screw from the GPIB module plate
using a T10 driver.
11 Detach the GPIB module connector from the IO
board.
12 Remove the GPIB module from the chassis.
Step Instructions Visuals
