Tests and Adjustments
Before You Begin
Table 3-1 Connector Care Quick Reference Guide
Handling and Storage
Do — Keep connectors clean Do Not — Touch mating-plane surfaces
— Extend sleeve or connector nut — Set connectors contact-end down
— Use plastic end-caps during storage — Store connectors or adapters loose
Visual Inspection
Do — Inspect all connectors carefully Do Not — Use a damaged connector - ever
— Look for metal particles, scratches, and
dents
Connector Cleaning
Do — Try compressed air first Do Not — Use any abrasives
— Use isopropyl alcohol
1
— Get liquid into plastic support beads
— Clean connector threads
Gaging Connectors
Do — Clean and zero the gage before use Do Not — Use an out-of-specification
connector
— Use the correct gage type
— Use correct end of calibration block
— Gage all connectors before first use
Making Connections
Do — Align connectors carefully Do Not — Apply bending force to connection
— Make preliminary connection contact
lightly
— Over tighten preliminary connection
— Turn only the connector nut — Twist or screw any connection
— Use a torque wrench for final
connection
— Tighten past torque wrench “break”
point
1. Cleaning connectors with alcohol shall only be done with the instrument’s power cord removed, and
in a well-ventilated area. Allow all residual alcohol moisture to evaporate, and the fumes to dissipate
prior to energizing the instrument.
To Next Page
