03 | Keysight | FieldFox Handheld Analyzers - Configuration Guide
RF and microwave
(combination) analyzer
Microwave vector
network analyzer (VNA)
Microwave spectrum
analyzer (SA)
Option Description N991xA
N995xA
N992xA N993xA
N996xA
CAT/vector network analysis
010 VNA time domain √ √ —
112 QuickCal √ on N991xA
- on N995xA
√ —
210
VNA transmission/reflection
√ Base model
—
211
VNA full 2-port S-parameters √
√
—
212 1-port mixed-mode S-parameters √ √ —
215 TDR cable measurements √ √ —
305 Cable and antenna analyzer Base model √ Note 1
308 Vector voltmeter √ √ —
320 Reflection meas. (RL, VSWR and scalar meas.) Note 2 Note 2 √
Spectrum analysis
209 Extended range transmission analysis (ERTA) √ — √
220 Tracking generator Note 3 — √
233 Spectrum analyzer √ — Base model
235 Pre-amplifier √ — √
236 Interference analyzer and spectrogram √ — √
238 Spectrum analyzer time gating √ — √
312 Channel scanner √ — √
350 Real-time spectrum analyzer (RTSA) √ - on N9912A — √
351 I/Q Analyzer (IQA) √ - on N9912A — √
355 Analog demodulation √ — √
Power measurements
208 USB power sensor meas. versus frequency √ √ √
302 USB power sensor support √ √ √
310 Built-in power meter √ √ √
330 Pulse meas. with USB peak power sensor √ √ √
System features
030 Remote control capability √ √ √
307 GPS receiver √ √ √
309 DC bias variable-voltage source √ √ √
Windows based software
89601B 89600 VSA Software √ - on N9912A — √
Notes:
Base model means that the functionality listed is the primary function of that instrument. For example, on the N991xA or N995xA combo analyzers,
cable and antenna analysis is the standard function included with every N991xA or N995xA.
1. Option 305 is not available on the N993xA or N996xA. However, a subset of cable and antenna analyzer measurements, return loss and VSWR, is available
as Option 320.
2. Option 320 is not applicable to N991xA, N995xA, or N992xA. The reflection measurements of return loss and VSWR are included with every N991xA,
N995xA, and N992xA. So there is no need for an Option 320 on these analyzers.
3. On the N991xA or N995xA analyzers, order Options 233 and 210 to obtain a tracking generator with the spectrum analyzer. There is no Option 220 on the
N991xA or N995xA analyzers. To obtain tracking generator capability, you need Options 233 and 210. Option 233 provides the spectrum analyzer capability
and Option 210 the “tracking” capability.
The FieldFox Handheld Analyzer Family
This configuration guide describes configurations, options and accessories for the FieldFox family of portable analyzers. This guide
should be used in conjunction with the technical overview and data sheet for a complete description of the analyzers. The table below
shows a comparison of the functions available in the FieldFox family of analyzers.
The following accessories are included with every FieldFox: AC/DC adapter, battery, soft carrying case, LAN cable and Quick Reference
Guide.
Note: Combination analyzer (combo) = Cable and antenna tester (CAT) + Vector network analyzer (VNA) + Spectrum analyzer (SA)
FieldFox family and options
