04 | Keysight | FieldFox Handheld Analyzers - Configuration Guide
FieldFox RF and Microwave (Combination) Analyzers
FeldFox RF and microwave (combination) analyzer models
Step 1. Select the model that provides the desired frequency range.
Model Description CAT and VNA frequency SA frequency
1
Test port connectors
N9913A 4 GHz FieldFox RF analyzer 30 kHz to 4 GHz 100 kHz to 4 GHz Type-N (f)
N9914A 6.5 GHz FieldFox RF analyzer 30 kHz to 6.5 GHz 100 kHz to 6.5 GHz Type-N (f)
N9915A 9 GHz FieldFox microwave analyzer 30 kHz to 9 GHz 100 kHz to 9 GHz Type-N (f)
N9916A 14 GHz FieldFox microwave analyzer 30 kHz to 14 GHz 100 kHz to 14 GHz Type-N (f)
N9917A 18 GHz FieldFox microwave analyzer 30 kHz to 18 GHz 100 kHz to 18 GHz Type-N (f)
N9918A 26.5 GHz FieldFox microwave analyzer 30 kHz to 26.5 GHz 100 kHz to 26.5 GHz 3.5 mm (m)
N9950A 32 GHz FieldFox microwave analyzer 300 kHz to 32 GHz 9 kHz to 32 GHz NMD 2.4 mm (m)
N9951A 44 GHz FieldFox microwave analyzer 300 kHz to 44 GHz 9 kHz to 44 GHz NMD 2.4 mm (m)
N9952A 50 GHz FieldFox microwave analyzer 300 kHz to 50 GHz 9 kHz to 50 GHz NMD 2.4 mm (m)
Step 2. Select optional measurement capabilities.
Any of these options can easily be added as a software upgrade in the future.
Exception: Option 112 is only applicable to N991xA models. It is not applicable to N995xA models.
FieldFox RF and microwave (combination) analyzer options
Option Description Prerequisite options/notes
CAT/vector network analysis
010 VNA time domain Requires 210, recommend 211
112 QuickCal Not available for N995xA models. See page 5, FAQ #9
210 VNA transmission/reflection Recommend ordering a cal kit
211 VNA full 2-port S-parameters Requires 210, recommend ordering a cal kit
212 1-port mixed-mode S-parameters Requires 210 and 211
215 TDR cable measurements -
308 Vector voltmeter 210 and 211 required to obtain full VVM functionality. See page 5, FAQ #8
Spectrum analysis
209 Extended range transmission analysis (ERTA) Requires 233 and 210. Recommend 307. Requires two FieldFoxes. See page 6, FAQ # 10.
233 Spectrum analyzer -
235 Pre-amplifier Requires 233
236 Interference analyzer and spectrogram Requires 233
238 Spectrum analyzer time gating Requires 233
312 Channel scanner Requires 233
350 Real-time spectrum analyzer (RTSA)
3
Requires 233, Recommend 235.
351 I/Q Analyzer (IQA)
3
Requires 233
355 Analog demodulation Requires 233
Power measurements
208 USB power sensor meas. versus frequency Requires 302
302 USB power sensor support Need to order USB power sensor
2
310 Built-in power meter No power sensor required. See page 8, FAQ #1
330 Pulse meas. with USB peak power sensor Need to order USB peak power sensor. See page 9, FAQs #7 and #8
System features
030 Remote control capability Requires an iOS device
307 GPS receiver Need to order GPS antenna, N9910X-825. See page 9, FAQ #3
309 DC bias variable-voltage source -
Windows based software
89601B 89600 VSA Software
3
Requires 233
1. Usable to 5 kHz
2. List of compatible sensors available from www.keysight.com/find/fieldfoxsupport
3. Requires CPU2 fast processor. See page 6, FAQ #13
