11 | Keysight | PXI Vector Network Analyzer - Configuration Guide
www.keysight.com/find/pxivna
For devices with 3.5 mm or SMA connectors
Mechanical calibration kits
– 85052B Standard, DC to 26.5 GHz
Includes:
00902-60003 3.5 mm (m) fixed load
00902-60004 3.5 mm (f) fixed load
00911-60019 3.5 mm (m) sliding load
00911-60020 3.5 mm (f) sliding load
85052-60006 3.5 mm (m) short
85052-60007 3.5 mm (f) short
85052-60008 3.5 mm (m) open
85052-60009 3.5 mm (f) open
85052-60012 3.5 mm (f) to 3.5 mm (f) adapter
85052-60013 3.5 mm (f) to 3.5 mm (m) adapter
85052-60014 3.5 mm (m) to 3.5 mm (m) adapter
– 85052C Precision TRL, DC to 26.5 GHz
Includes:
00902-60003 3.5 mm (m) fixed load
00902-60004 3.5 mm (f) fixed load
85052-60006 3.5 mm (m) short
85052-60007 3.5 mm (f) short
85052-60008 3.5 mm (m) open
85052-60009 3.5 mm (f) open
85052-60032 3.5 mm (f) to 3.5 mm (f) adapter
85052-60033 3.5 mm (m) to 3.5 mm (m) adapter
85052-60034 3.5 mm (f) to 3.5 mm (m) adapter
85052-60035 3.5 mm short TRL line
85052-60036 3.5 mm long TRL line
– 85052D Economy, DC to 26.5 GHz
Includes:
00902-60003 3.5 mm (m) fixed load
00902-60004 3.5 mm (f) fixed load
85052-60006 3.5 mm (m) short
85052-60007 3.5 mm (f) short
85052-60008 3.5 mm (m) open
85052-60009 3.5 mm (f) open
85052-60012 3.5 mm (f) to 3.5 mm (f) adapter
85052-60013 3.5 mm (f) to 3.5 mm (m) adapter
85052-60014 3.5 mm (m) to 3.5 mm (m) adapter
Electronic calibration kits
– N7550A economy ECal, DC to 4 GHz, 2-ports
– N7551A economy ECal, DC to 6.5 GHz, 2-ports
– N7552A economy ECal, DC to 9 GHz, 2-ports
– N7553A economy ECal, DC to 14 GHz, 2-ports
– N7554A economy ECal, DC to 18 GHz, 2-ports
– N7555A economy ECal, DC to 26.5 GHz, 2-ports
– N755xA Series includes:
Option 3MF with 3.5 mm (m) to 3.5 mm (f) ECal module
Option 3MM with 3.5 mm (m) to 3.5 mm (m) ECal module
Option 3FF with 3.5 mm (f) to 3.5 mm (f) ECal module
– 85093C RF ECal, 300 kHz to 9 GHz, 2-ports
Standard module includes
85093C-xxx mixed-connector options:
Port A option Port B option
Type (f) (m) Type (f) (m) Type (f) (m)
3.5 mm 101 102 Type-N
50 ohm
203 204 7-16 205 206
– N4431B Microwave ECal, 300 kHz to 13.5 GHz, 4-ports
Includes:
Option 010 module with:
N4431-60006 4 x 3.5 mm (f) ECal module
N4431B-xxx mixed-connector options:
Connector Port A Port B Port C Port D
Type Option Option Option Option
3.5 mm (f) 101 201 301 401
3.5 mm (m) 102 202 302 402
Type-N 50 ohm (f) 103 203 303 403
Type-N 50 ohm (m) 104 204 304 404
7-16 (f ) 105 205 305 405
7-16 (m) 106 206 306 406
– N4433A Microwave ECal, 300 kHz to 20 GHz, 4-ports
Includes:
Option 010 module with:
N4433-60003 4 x 3.5 mm (f) ECal module
N4433A-xxx mixed-connector options:
Connector Port A Port B Port C Port D
Type Option Option Option Option
3.5 mm (f) 101 201 301 401
3.5 mm (m) 102 202 302 402
– N4691B Microwave ECal, 300 kHz to 26.5 GHz, 2-ports
Includes:
Option M0F module with:
N4691-60004 3.5 mm (f) to 3.5 mm (m) ECal module
Option 00M module with:
N4691-60005 3.5 mm (m) to 3.5 mm (m) ECal module
Option 00F module with:
N4691-60006 3.5 mm (f) to 3.5 mm (f) ECal module
Option 00A adds:
85052-60012 3.5 mm (f) to 3.5 mm (f) adapter
85052-60014 3.5 mm (m) to 3.5 mm (m) adapter
Option M0F with:
85093-60008 3.5 mm (f) to 3.5 mm (m) ECal module
Option 00F module with:
85093-60010 3.5 mm (f) to 3.5 mm (f) ECal module
Option 00M module with:
85093-60009 3.5 mm (m) to 3.5 mm (m) ECal module
Option 00A adds:
85052-60012 3.5 mm (f) to 3.5 mm (f) adapter
85052-60014 3.5 mm (m) to 3.5 mm (m) adapter
