Keysight Technologies N9000B Configuration Guide

02 | Keysight | N9000B CXA X-Series Signal Analyzer, Multi-touch - Configuration Guide
Congure Your Keysight CXA Signal Analyzer
This step-by-step process will help you congure your new CXA X-Series signal analyzer.
Tailor the performance to meet your requirements.
Included in base product
Standard options and accessories come with the CXA base model at no additional
charge and do not need to be ordered. They include:
– Spectrum analyzer measurement application
– Dual-core, high-performance processor, 8 GB RAM, removable solid-state drive
– Frequency reference
– 10 MHz analysis bandwidth
– Enhanced phase noise
– Windows Embedded Standard 7
– Benchtop conguration
– Mouse
– User guide
– Power cord
– 3-year return-to-Keysight warranty
Step 1. Select maximum frequency range (required option; frequency range not upgradeable)
Description Option number Additional information
Frequency range, 9 kHz to 3.0 GHz N9000B-503
Frequency range, 9 kHz to 7.5 GHz N9000B-507
Frequency range, 9 kHz to 13.6 GHz N9000B-513
Frequency range, 9 kHz to 26.5 GHz N9000B-526
Step 2. Add a preamplier
Description Option number Additional information: Preampliers improve the noise oor for low-level signal
detection; +20 dB: 100 kHz to 26.5 GHz
Preamplier, 100 kHz to 3.0 GHz N9000B-P03 Compatible with N9000B-503, N9000B-507, N9000B-513,
and N9000B-526
Preamplier, 100 kHz to 7.5 GHz N9000B-P07 Compatible with N9000B-507, N9000B-513, and N9000B-526
Preamplier, 100 kHz to 13.6 GHz N9000B-P13 Compatible with N9000B-513 and N9000B-526
Preamplier, 100 kHz to 26.5 GHz N9000B-P26 Compatible with N9000B-526
Step 3. Choose frequency reference
Description Option number Additional information
Frequency reference Standard Aging rate: ± 1 x 10
–6
/year
Precision frequency reference N9000B-PFR Reduces frequency drift for more accurate measurements; aging rate: ± 1 x 10
–7
/year
Step 4. Choose an attenuator
Description Option number Additional information
Mechanical attenuator Standard 10 dB steps, 0 to 50 dB, for N9000B-503 and N9000B-507
10 dB steps, 0 to 70 dB, for N9000B-513 and N9000B-526
Fine resolution step attenuator N9000B-FSA Allows 2 dB steps for the full range of the attenuator
Step 5. Choose analysis bandwidth
Description Option number Additional information
10 MHz analysis bandwidth Standard Useful for most 2G and 3G measurement applications
25 MHz analysis bandwidth N9000B-B25 Extends the analysis (demod) bandwidth from 10 to 25 MHz; useful for most cellular
communications, wireless connectivity, and audio/video broadcasting measurement
applications
Get More Information
For a summary of specications,
refer to the N9000B CXA data
sheet (literature number 5992-
1274EN ).
A full set of specications are
available in the N9000B CXA
Signal Analyzer Specication
Guide at www.keysight.com/nd/
cxa_specications.

Keysight Technologies N9000B Specifications

General

Brand	Keysight Technologies
Model	N9000B
Category	Measuring Instruments
Language	English
