6 Installation Note N9030-90077
Option BBA, Analog Baseband I/Q Inputs Upgrade Kit
Tools Required
— T-10 Torx Driver
— T-20 Torx Driver
— 5/16-inch torque wrench
— 1/4-inch open end wrench
— 1/4-inch socket on 4 lb torque wrench
—scissors or knife
—diagonal cutters
— USB storage device with > 2 GB free memory
Keysight Service Center or Customer Calibration Lab:
The following kit items are not installed in the analyzer upgrade and need to be shipped back to the
end user for their use:
— 5063-2143, Probe tip BNC adapter
— 8120-2682, cable
Before you disassemble the instrument, turn the power switch to Standby, wait until the
instrument has completely shut down, and unplug the instrument. Failure to unplug the
instrument can result in personal injury.
Electrostatic discharge (ESD) can damage or destroy electronic components. All work on
electronic assemblies should be performed at a static-safe workstation. Refer to the
documentation that pertains to your instrument for information about static-safe workstations
and ordering static-safe accessories.
