16 | Keysight | 34970A Data Acquisition/Switch Unit Family - Technical Overview
34970A/34972A accuracy specifications ±(% of reading + % of range)
[1]
Includes measurement error, switching error, and transducer conversion error
Range
[3]
Frequency, etc.
24 hour
[2]
23 ±1°C
90 Day
23 ±5°C
1 Year
23 ±5°C
Temperature
coefficient
0 – 18°C, 28 - 55°C
DC voltage
100.0000 mV 0.0030 + 0.0035 0.0040 + 0.0040 0.0050 + 0.0040 0.0005 + 0.0005
1.000000 V 0.0020 + 0.0006 0.0030 + 0.0007 0.0040 + 0.0007 0.0005 + 0.0001
10.00000 V 0.0015 + 0.0004 0.0020 + 0.0005 0.0035 + 0.0005 0.0005 + 0.0001
100.0000 V 0.0020 + 0.0006 0.0035 + 0.0006 0.0045 + 0.0006 0.0005 + 0.0001
300.000 V 0.0020 + 0.0020 0.0035 + 0.0030 0.0045 + 0.0030 0.0005 + 0.0003
True RMS AC voltage
[4]
All ranges from 100.0000
mV to 100.0000 V
3 Hz–5 Hz 1.00 + 0.03 1.00 + 0.04 1.00 + 0.04 0.100 + 0.004
5 Hz–10 Hz 0.35 + 0.03 0.35 + 0.04 0.35 + 0.04 0.035 + 0.004
10 Hz–20 kHz 0.04 + 0.03 0.05 + 0.04 0.06 + 0.04 0.005 + 0.004
20 kHz–50 kHz 0.10 + 0.05 0.11 + 0.05 0.12 + 0.05 0.011 + 0.005
50 kHz–100 kHz 0.55 + 0.08 0.60 + 0.08 0.60 + 0.08 0.060 + 0.008
100 kHz–300 kHz
[5]
4.00 + 0.50 4.00 + 0.50 4.00 + 0.50 0.20 + 0.02
300.0000 V 3 Hz–5 Hz 1.00 + 0.05 1.00 + 0.08 1.00 + 0.08 0.100 + 0.008
5 Hz–10 Hz 0.35 + 0.05 0.35 + 0.08 0.35 + 0.08 0.035 + 0.008
10 Hz–20 kHz 0.04 + 0.05 0.05 + 0.08 0.06 + 0.08 0.005 + 0.008
20 kHz–50 kHz 0.10 + 0.10 0.11 + 0.12 0.12 + 0.12 0.011 + 0.012
50 kHz–100 kHz 0.55 + 0.20 0.60 + 0.20 0.60 + 0.20 0.060 + 0.020
100 kHz–300 kHz
[5]
4.00 + 1.25 4.00 + 1.25 4.00 + 1.25 0.20 + 0.05
Resistance
[6]
100.0000 Ω 1 mA current source 0.0030 + 0.0035 0.008 + 0.004 0.010 + 0.004 0.0006 + 0.0005
1.000000 kΩ 1 mA 0.0020 + 0.0006 0.008 + 0.001 0.010 + 0.001 0.0006 + 0.0001
10.00000 kΩ 100 µA 0.0020 + 0.0005 0.008 + 0.001 0.010 + 0.001 0.0006 + 0.0001
100.0000 kΩ 10 µA 0.0020 + 0.0005 0.008 + 0.001 0.010 + 0.001 0.0006 + 0.0001
1.000000 MΩ 5.0 µA 0.002 + 0.001 0.008 + 0.001 0.010 + 0.001 0.0010 + 0.0002
10.00000 MΩ 500 nA 0.015 + 0.001 0.020 + 0.001 0.040 + 0.001 0.0030 + 0.0004
100.0000 MΩ 500 nA || 10 MΩ 0.300 + 0.010 0.800 + 0.010 0.800 + 0.010 0.1500 + 0.0002
Frequency and period
[7]
100 mV to 300V 3 Hz–5 Hz 0.10 0.10 0.10 0.005
5 Hz–10 Hz 0.05 0.05 0.05 0.005
10 Hz–40 Hz 0.03 0.03 0.03 0.001
40 Hz–300 kHz 0.006 0.01 0.01 0.001
DC current (34901A only)
10.00000 mA <0.1 V burden 0.005 + 0.010 0.030 + 0.020 0.050 + 0.020 0.002+ 0.0020
100.0000 mA <0.6 V 0.010 + 0.004 0.030 + 0.005 0.050 + 0.005 0.002 + 0.0005
1.000000 A <2 V 0.050 + 0.006 0.080 + 0.010 0.100 + 0.010 0.005 + 0.0010
True RMS AC current (34901A only)
10.00000 mA
and
[4]
1.000000 A
3 Hz–5 Hz 1.00 + 0.04 1.00 + 0.04 1.00 + 0.04 0.100 + 0.006
5 Hz–10 Hz 0.30 + 0.04 0.30 + 0.04 0.30 + 0.04 0.035 + 0.006
10 Hz–5 kHz 0.10 + 0.04 0.10 + 0.04 0.10 + 0.04 0.015 + 0.006
100.0000 mA
[8]
3 Hz–5 Hz 1.00 + 0.5 1.00 + 0.5 1.00 + 0.5 0.100 + 0.06
5 Hz–10 Hz 0.30 + 0.5 0.30 + 0.5 0.30 + 0.5 0.035 + 0.06
10 Hz–5 kHz 0.10 + 0.5 0.10 + 0.5 0.10 + 0.5 0.015 + 0.06
Temperature Type 1-year accuracy
[9]
Extended range 1-year accuracy
[9]
Temp coefficient/ºC
Thermocouple
[10]
B 1100 to 1820°C 1.2°C 400 to 1100°C 1.8°C
0.03°C
E –150 to 1000°C 1.0°C –200 to -150°C 1.5°C
J –150 to 1200°C 1.0°C –210 to -150°C 1.2°C
K –100 to 1200°C 1.0°C –200 to -100°C 1.5°C
N –100 to 1300°C 1.0°C –200 to -100°C 1.5°C
R 300 to 1760°C 1.2°C –50 to 300°C 1.8°C
S 400 to 1760°C 1.2°C –50 to 400°C 1.8°C
T –100 to 400°C 1.0°C –200 to -100°C 1.5°C
RTD R0 from 49 Ω to 2.1 kΩ –200 to 600°C 0.06°C 0.003°C
Thermistor 2.2 k, 5 k, 10 k –80 to 150°C 0.08°C 0.002°C
[1] Specifications are for 1 hr warm-up and 6½ digits, Slow ac filter
[2] Relative to calibration standards
[3] 20% over range on all ranges except 300 Vdc and ac ranges and 1 Adc
and ac current ranges
[4] For sinewave input > 5% of range� For inputs from 1% to 5% of range
and < 50 kHz, add 0�1% of range additional error
[5] Typically 30% of reading error at 1 MHz, limited to 1 x 108 V Hz
[6] Specifications are for 4- wire ohms function or 2-wire ohms using scaling
to remove the offset. Without scaling, add 4 Ω additional error in 2-wire
Ohms function
[7] Input > 100 mV� For 10 mV to 100 mV inputs multiply % of reading error x 10
[8] Specified only for inputs >10 mA
[9] For total measurement accuracy, add temperature probe error
[10] Thermocouple specifications not guaranteed when 34907A module
is present� For < 1°C accuracy, a precision external reference is required�

Keysight 34970A Specifications

General

Maximum Voltage	300 V
Maximum Current	1 A
Relay Type	Electromechanical
Type	Data Acquisition/Switch Unit
Slots	3
Connectivity	GPIB, RS-232
DC Voltage Range	100 mV to 300 V
AC Voltage Range	100 mV to 300 V
Resistance Range	100 Ω to 100 MΩ
Switch Type	Multiplexer, Matrix, General Purpose
Voltage Measurement Range	100 mV to 300 V
Temperature Measurement	Thermocouple, RTD, Thermistor
Switching Speed	60 channels/sec
DC Current Range	1 mA to 1 A
AC Current Range	1 mA to 1 A
Frequency Range	3 Hz to 300 kHz
Scan Rate	Up to 250 channels/sec
Current Measurement Range	1 µA to 1 A
Resistance Measurement Range	100 mΩ to 100 MΩ
