Keystone KSTAD224D - Identification of Unit Components; Front and Rear Components; Included Accessories

66
IDENTIFICATION OF P
ARTS
Power Cord and plug
Drain hose outlet
Band(Used only when
storing the unit.)
Front
Rear
Air outlet grille
Caster
Identification of parts
Fig.2
Fig.3
Air filter (behind the grille)
Control panel
Air intake grille
Water bucket
1
2
3
4
5
1
2
3
4
NOTE: All the pictures
in the manual are
for explanation purposes only. The actual
shape of the unit you purchased may be
slightly different, but the operations and
functions are the same.
Accessories:
Drain hose(1pc) adaptor
A(1pc) screw(2pc)
6
Handle (both sides)
1
2
3
1
2
4
5
3
6
