Keystone KSTAP05PHA - Page 6

FRONT REAR
Control panel
Handle
(both sides)
Horizontal louver
control lever(adjust
manually)
Vertical louver
control lever
(adjust manually)
Panel
Caster
Bottom tray
drain outlet
Air filter
Upper air intake
air outlet
Lower air intake
Drain outlet
Design Notice: In order to ensure the optimal performance of our products, the design specifications of the unit and remote
control are subject to change without prior notice.
