KFV SIEGENIA DRIVE IO module - Master Mode in Stand-Alone

SIEGENIA access control systems

IO module/IO module smart
05.202018/24 H39.ELEKS010EN-00
9.4.2 In stand-alone mode

SIEGENIA ACS.
IO module smart and top-hat rail power supply via SI-BUS

terminal strip
Class 2 output
Art.No. 3509884
100-240VAC
24-28VDC/2.5-2.14A
DC OK
+
V V V V
+
- -
V.ADJ
Ein Unternehmen der SIEGENIA GRUPPE
L N
Schutzleiter (PE) &
Abschirmung anschliessen
Connect Shield &
Earth-Connection (PE)
2
1
3
Class 2 output
Art.No. 3509884
100-240VAC
24-28VDC/2.5-2.14A
DC OK
+
V V V V
+
- -
V.ADJ
Ein Unternehmen der SIEGENIA GRUPPE
L N
Schutzleiter (PE) &
Abschirmung anschliessen
Connect Shield &
Earth-Connection (PE)
2
1
3
Item Name
1 IO module smart
2 Top-hat rail power supply;

Top-hat rail power supply


V+ 24V DC (+) In
V- 24V DC (-) In
3 





11 = 24 V DC (-) In
12 = 24 V DC (+) in
