FZ-USV-230 (SXM 2540) [ENG]
Stand: 10.03.2008 page 16 from 21
4.2. Power Supply input connection
Before connecting the power to the unit it is advisable to review the wiring diagram
again for correct installation (see Fig 1) .
Before connecting the AC power ON check the output voltage selector to ensure
that it is correct ;
Jumper 1 OFF = 12 VDC
Jumper 1 ON = 24 VDC (Genius / Fliethomatic)
The actual output voltage is Factory set and re-adjusting it will void the warranty.
4.3. Output Connections
Connect the Genius or Fliethomatic to the terminals DC (+) and DC (-) observing
polarity (see Fig. 2).
Terminal 2 = + = DC (+)
Terminal 3 = - = DC (-)
Ground (Shielded) = - = DC (-) =
