4. ACCESS TO THE OCCUPANTS
4.5 Occupants Rescue Guide
When dealing with an emergency situation, refer to the components as below.
Do not cut the body near the airbag, high-voltage cable, high-voltage system.
Supplemental Restraint System
Control Module (SRSCM)
Airbag
Airbag Inflator
High-voltage cable
Air-conditioning line
Seat belt pretentioner
Cable Cut (with the service plug that
can disable the high-voltage system)
12 V battery
High-voltage Battery
Air-conditioning
component
High-voltage
component
12 V battery (-) connector
High-voltage charge port
4WD, long-range model, 6P
Ultra-High Strength
Steel
Kia EV9
Emergency Response Guide
13
