5. STORED ENERGY / LIQUIDS / GASES / SOLIDS
5.1 High-voltage System
1. Vehicle Charging Management System (VCMS)
2. Combo Charger Inlet Assembly
3. Integrated Charging Control Unit (ICCU)
4. Motor & Reduction Gear Assembly
5. Rear High Voltage Junction Box
6. Multi Inverter Assembly
7. Battery System Assembly (BSA)
8. 12 V Auxiliary Battery
9. Front High Voltage Junction Box
Kia EV9
Emergency Response Guide
15
