3
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS.
*IF EQUIPPED
MPH
8
7
6
5
4
3
2
1
0
HC E F
x1000rpm
100
80
60
40 120
20 140
0 160
20
40
60
80
100
120
140
160
180
200
220
240
2600
km/h
AUTO
(Cluster Type C shown)
A
G
B
CC
F
DE
Instrument Cluster Overview
A
Tachometer
B
Speedometer
C
Turn Signal Indicators
D
LCD Screen/Odometer/Tripmeter
E
Gear Shift Position Indicator
F
Fuel Gauge
G
Engine Coolant Temperature Gauge
Your vehicle’s instrument cluster & indicator light
locations may differ from those in the illustrations.
For more information on the instrument cluster, the
LCD Warning Messages and the function of all indicator
and warning lights, please refer to the Owner’s Manual.
This illustration is for demonstration purposes only.
Some indicators and warning lights may not appear in
illustration. On the vehicle, they may appear in the LCD.
INSTRUMENT CLUSTER
