Maintenance
7
7-89
Fuse Name Fuse rasting Circuit Protected
DR Lock RH 10A Passenger Door Module, Rear Door Module RH
DR Lock LH 10A Driver Door Module, Rear Door Latch LH
S/Heater RR
RH
15A Rear Seat Warmer Control Module RH, Rear CCS Control Module RH
S/Heater RR
LH
15A Rear Seat Warmer Control Module LH, Rear CCS Control Module LH
Spare 15A Spare
Fuse Name Fuse rasting Circuit Protected
Start 2 40A Metal Core Block (PCB #2) (Fuse : F8, F9, F12)
AMS 10A Battery Sensor
Battery 6 100A Rear Smart Junction Box (Fuse : F1, F2, F3, F4, F5, F6, F7, F8, F10, F11, F13, F15, F17, F18, F19, F20)
Battery box fuse panel
