Kia Sorento 2003 - REMOVAL

REMOVAL
1.
IG OFF and wait for 30 seconds.
2.
Disconnect the battery groud terminal.
3.
Lift the passenger side carpet (for LHD vehicle), and then remove the protection plate.
4.
Remove the ECU mounting nuts.
5.
Disconnect ECU harness connector. To do this, pull locking clip.
6.
Unscrew four fixing bolts and remove ECU.
