3
PRODUCT OVERVIEW
SPECIFICATIONS
SOC Display with
Energy Ring
Instantaneous Current
Draw (+ or -)
Battery Voltage
Back Button
OK Button
Temperature
Time Remaining
to Full/Empty
Charge/Discharge
Battery
Up Button
Down Button
Description
Working Voltage Range
Working current (backlight on)
Standby current (backlight off)
Accuracy
Battery Capacity Range
Operating Temperature Range
Display Housing Dimensions
B+ Wire
Display Temperature Sensor Cable
Display Data Cable
Shunt Assembly Data Cable
Optional extension cable wire length
Parameter
10-30V DC
~100 mA
~1-2 mA
1%
0.1 - 999.9Ah
-10º to 60º
126L x 66.6H
20AWG, Length: 100mm
5m
500mm
500mm
Recommended 5m Extension Cable
