KickAss KAMPPTRC - Installation Instructions; Installation on a Controller Case or Panel; Installation on a Wall

External dimensions: 115.82×115.82mm
Installation dimensions: 96mm or 103.82x103.82mm
Installation hole diameter: ￠3.5 (mm)
Front
Right view
External dimensions: 118.5×118.5×48mm
Installation dimensions: 50×50mm or 70×70mm
Installation hole diameter: ￠5(mm)
5.2、Installation on a wall
5. INSTALLATION INSTRUCTIONS
5.1 Installation on a controller case or panel
