2
BX AMPLIFIERS
BX.1-SERIES AMPLIFIERS Owner’s Manual
PERFORMANCE
Authorized KICKER Dealer:
Purchase Date:
Model Number:
Serial Number:
Model: BX350.1 BX550.1
RMS Power, all channels driven
@ 14.4V, 4Ω ≤ 1% THD+N
@ 14.4V, 2Ω ≤ 1% THD+N
200W x 1
350W x 1
300W x 1
550W x 1
Length 300mm 370mm
Specifications common to all models:
Height 54mm
Width 220mm
Frequency Response ± 1dB 5Hz–30000Hz
Signal-to-noise Ratio >95dB, A-weighted, re: rated power
Input Sensitivity Low Level:
200mV–4V
High Level:
500mV–10V
Selectable Electronic Crossover OFF (bypass)
LP/BP variable | 50–200Hz, 12dB/octave
HP variable | 10–50Hz, 12dB/octave
Bass Boost Variable | 0–12dB @ 40Hz
MODEL: BX350.1 / BX500.1
