Kicker CompVR - Page 24

POWER HANDLING:
200W with 25Hz Subsonic Filter
set at 24db/Octave.
Without subsonic filter 170W
1.75 cf, Fb=40Hz
.30 cf = Port Vol.
CompVR10-BOX-VENTED-175
Side View
Front View
Cut List: 3/4" MDF
(2) 14" x 12" Top & Bottom(A)
(2) 14" x 27 3/4" Sides(B)
(2) 10 1/2" x 27 3/4" Front & Back(C)
(1) 10 1/2" x 19 1/4" Port(D)
(4) 2" x 2" Gusset(E)
2-1/2
20
29-1/4
B
D
E
12
C
14
3/4
A
R 3/8
2-1/2
3/4
10-1/2
∅ 9-5/32
6
6
Kicker CompVR Subwoofers
Recommended Applications
Page 24
