Kicker CompVR - Page 25

Kicker CompVR Subwoofers
Recommended Applications
Page 25
POWER HANDLING:
300W with 25Hz Subsonic Filter
set at 24db/Octave.
Without subsonic filter 125W
1.75 cf, Fb=40Hz
.38 cf = Port Vol.
CompVR12-BOX-VENTED-175
Side View
Front View
Cut List: 3/4" MDF
(2) 13 1/4" x 14" Top & Bottom(A)
(2) 13 1/4" x 26 1/2" Sides(B)
(2) 12 1/2" x 26 1/2" Front & Back(C)
(1) 12 1/2" x 20" Port(D)
(4) 2" x 2" Gusset(E)
2-1/2
20
29-1/4
B
D
E
14
C
13-1/4
3/4
A
R 3/8
2-1/2
3/4
12-1/2
∅ 10-15/16
7
7
