Dual Zone Digital Location Control Unit Installation and Operation Manual 16
Figure 9: Wiring configuration to monitor outputs
Note: The end-of-line (EOL) and alarm resistor values are not specified these
values are determined by the monitoring circuit.
C
+
-
Fault
Alarm
+
-
Detection zone of
conventional fire panel or
addressable zone
monitor/switch monitor
interface of an addressable
fire panel
LHD ZONE 1
EOL
resistor
Alarm
resistor
