19 Dual Zone Digital Location Control Unit Installation and Operation Manual
Configuring the operating mode
This option configures the operating mode (independent or interlock).
Press SELECT to toggle between Independent and Interlock, and then press
SET to confirm the selection.
OPERATING MODE:
INDEPENDENT
OPERATING MODE:
INTERLOCK
See “Operating modes” on page 7 for more information on the two operating
modes.
Configuring the cable type
This option configures the sensor cable type (the alarm temperature). Both zones
(Z1, Z2) must be configured.
Press SELECT to scroll through the available temperature values for Z1, and
then press SET to confirm the selection.
Z1 CABLE TYPE:
68C
Repeat the process for Z2.
Configuring the leader cable
This option configures the leader cable (YES, NO). Both zones (Z1, Z2) must be
configured.
Press SELECT to scroll between YES and NO for Z1, and then press SET to
confirm the selection.
Z1 LDR CABLE:
NO
Z2 LDR CABLE:
NO
If no leader cable is used, select NO for both zones.
If either zone uses leader cable:
1. Select YES for zone leader cable for Z1, and then press the SET to confirm
the selection.
Z1 LDR CABLE:
YES
The control unit then asks if the LHD zone is ready to calibrate.
READY TO
CALIBRATE?
