Dual Zone Digital Location Control Unit Installation and Operation Manual 18
Menu options
There are three menu options, as shown below. Press SELECT to scroll through
the options and SET to confirm a selection.
MAIN MENU
LOAD CONFIGS
MAIN MENU
NEW CONFIGS
MAIN MENU
SELF TEST
Load the current configuration settings
Select LOAD CONFIGS to load the current configuration settings, and then press
SET to confirm the selection.
When this option is selected, the LCD displays the following message.
LOADING SAVED
CONFIGS…
The LCD then scrolls through the configured settings.
Create a new configuration
Select NEW CONFIGS to configure new system settings, and then press SET to
confirm the selection.
MAIN MENU
NEW CONFIGS
The first configuration option (operating mode) is then displayed on the LCD.
OPERATING MODE:
INDEPENDENT
The control unit guides you through the configuration options one at a time to
ensure no settings are missed. See “Configuring the operating mode” on page
19.
If an error is made during the configuration process, press SET and SELECT at
the same time for 10 seconds – the LCD returns to the first configuration menu
option.
Self Test
MAIN MENU
SELF TEST
Performs a self test to check the functionality of the control unit. Select SELF
TEST to start the test. See “Testing” on page 25.
