WARNING: Turn off the main power to the circuit before wiring. Route the AC supply/interconnect cable into the dry
lining box or Kidde surface pattress
• Affix the CO alarm mounting plate to the dry lining box or Kidde surface pattress using suitable screws.
• Using a suitably-rated terminal block, connect the neutral supply to the blue wire of the connector plug and the live
supply to the brown wire.
• If interconnecting is required, connect the white wire of the connector plug to the designated interconnect
conductor of the 4-core supply cable.
• NOTE: Do not use an earth wire for the interconnect conductor.
• NOTE: If this is to be a single-station CO alarm, connect the white wire to an unused terminal block.
• Attach the connector plug to the back of the CO alarm. The plug will only fit one way and will snap into place.
• Slide switch on rear of alarm to on position.
• Align alarm with mounting plate and rotate clockwise into place.
• Test CO alarm. See section 5 “Testing”.
WARNING: Failure to properly install and activate this alarm will prevent proper operation of this alarm and will
prevent its response to CO hazards.
Interconnect Model Capability
Pf FirexCO TiKIDDE
KF10R 1SFWR Mains Ionisation Alarm with rechargeable battery back-up
KF10 1SFW Mains Ionisation Alarm with alkaline battery back-up
KF20R 2SFWR Mains Optical Alarm with rechargeable battery back-up
KF20 2SFW Mains Optical Alarm with alkaline battery back-up
KF30R 3SFWR Mains Heat Alarm with rechargeable battery back-up
KF30 3SFW Mains Heat Alarm with alkaline battery back-up
4MCO Mains CO Alarm with rechargeable battery back-up
4MDCO Mains CO Alarm with rechargeable battery back-up, digital display
K4MCO Mains CO Alarm with rechargeable battery back-up
