P/N 03-0210-501-4300-05 • ISS 24OCT23 3 / 26
Wiring
For optimal system performance, use 0.13 to 3.31 mm² (0.40
to 2.05 mm) twisted-pair cable with a maximum length of 2 km.
Wire the unit as described below. Observe the indicated
polarity.
Terminal
Description
A
+ Positive line (+)
B
+ Positive line (+)
A
Negative line (–)
B
Negative line (–)
Device status
The device status is indicated by two colour changing LEDs on
the front of the unit, as shown in the table below.
State
Indication
Alarm
Steady red LEDs [1]
Isolation active
Steady yellow LEDs [2]
Fault
Flashing yellow LEDs
Communicating
Flashing green LEDs
[1] This may also indicate an active Locate Device command from the
control panel.
[2] KE-DM3110 models only.
Maintenance and testing
Maintenance
The unit should be maintained and tested according to local or
national requirements and any other applicable regulations. Do
not modify internal wiring or circuitry.
Testing
To activate an alarm, push the resettable element or turn the
key clockwise (one click). To reset the device, turn the key
anticlockwise (one click). Reset the control panel after testing.
Replacing the resettable element
Replace the resettable element (or add the breakable element)
as follows:
1. Unlock and remove the front cover as described in
Installationon page 2.
2. Push the element up, and then pull it out (see Figure 5).
3. Replace the resettable element (or add the breakable
element, if required).
4. Replace the front cover.
Analogue values
Analogue values for diagnosing and troubleshooting device
status are shown in the table below.
Value
Device Status
32
Normal
128
Alarm
Specifications
Electrical
Operating voltage
17 to 38 VDC
Current consumption
Standby
KE-DM3010
KE-DM3110
Alarm
KE-DM3010
KE-DM3110
180 µA
200 µA
2.8 mA
2.8 mA
Isolation
The following isolation specifications apply to KE-DM3110
models with an integrated short circuit isolator.
Current consumption
(isolation
active
)
1.5 mA
Isolation
voltage
Minimum
Maximum
14 VDC
15.5 VDC
Reconnect voltage
Minimum
Maximum
14 VDC
15.5 VDC
Rated current
Continuous (switch closed)
Switching (short circuit)
1 A
1 A
Leakage current
1 mA max.
Series impedance
0.06 Ω max.
Number of isolators per loop
128 max.
Number of devices between
isolators
32 max.
Mechanical and environmental
IP rating
IP41
Bac
kbox cable knockouts
Back
Top/bottom [1]
1 × Ø 20 mm
1 × Ø 27 mm
2 × Ø 22 mm
Wire size
Minimum
Maximum
0.13 mm² (0.40 mm)
3.31 mm² (2.05 mm)
Operating environment
Operating temperature
Storage temperature
Relative humidity
−25 to +72°C
−25 to +72°C
10 to 95% (noncondensing)
Colour
Red
Blue
Green
Orange
White
Yellow
RAL3028
RAL5005
RAL6024
RAL2008
RAL9003
RAL1003
Material
Body
Contacts
ABS, PC, PMMA, POM
Nickel plated H59, tin plated
QSn6.5-0.1, tin plated H65
Weight
Without backbox
With backbox [2]
110 g
165 g
