Kidde VM-1 Technical Reference Manual

Chapter 7: Service and troubleshooting
152 P/N 3101890-EN • REV 006 • ISS 21JUN18
Note: If the detector is removed from an isolator base, the isolator will transfer.
Figure 51: Detectors removed for service
(1) Removed detectors
If the devices are returned to their original locations, as shown in Figure 52, the map supervision function
recognizes the detectors have been returned as originally installed and mapped, and no additional action is taken.
Figure 52: Detectors returned to original location
(1) Detectors returned
If the devices are returned to different locations, the map supervision function recognizes that previously mapped
serial numbers occupy new map locations. When the mapping supervision function recognizes the need to remap
the loop, the panel is put in the map pending state. In the map pending state, the panel automatically remaps the
loop when the quantity of reinstalled devices is equal to or greater than the quantity of devices defined in the
original map. If the control panel is connected to the computer running the VM-CU, the Current Status tab on the
V-Series Status / Diagnostics window indicates Mapping Pending.
001
101
102
203
204
IPHS, S/N 33-1
PHS, S/N 34-1
CT1, S/N 48-1
CT2, S/N 49-1
(1)
001
101
102
203
204
IPHS, S/N 33-1
PHS, S/N 34-1
CT1, S/N 48-1
CT2, S/N 49-1
(1)
