Assembly Instruction
• Insert a Big Washer (W) to a side of the Front Axle, follow by the Wheel (D), then secure a Small washer (X)
and Nut (S) by the spanner. Cover the nut with a Small Wheel Cover (E)
• Repeat the same st .
• Insert 2 Rear Spring Holders ( F) to the car body, and secure using M4 x 14 screws (R).
(W) Big Washer
(D) Wheel
(X) Small Washer
(S) Nut
(E) Small Wheel Cover
Tool required:
Front wheel assembly:
Parts and Feature
P. Seat
1x
T. Remote Control
1x
Q. Spanner
2x
U. Charger
1x
R. M4 x 14 Screw
14x
W. Big Washer
2x
(For front axle inner side)
X. Small Washer
5x
11
(R) M4 x 14 Screw
(F) Rear Spring Holder
ep on the other side
