Kidzone JC111B - Assembly: Rear Axle and Motors; Rear Axle and Motor Integration

Assembly Instruction
• Insert Rear Axle (N) through the opening hole of the Rear Spring Holders.
• Insert Motors (J) to each end of the rear axle. (the motor mark with “L” or “R”, pls. match to
corresponding marking (L/R) on the chassis as above diagram for assemble)
• Assemble Wheel (D) to the rear axle and secure with a Small Washer (X) and Nut (S). Then cover with
Small Wheel Cover (E).
• Repeat the same step for the another wheel.
(J) Motor
(N) Rear Axle
(D) Wheel
(X) Small Washer
(S) Nut
Tool required:
(E) Small Wheel Cover
Parts and Feature
P. Seat
1x
T. Remote Control
1x
Q. Spanner
2x
U. Charger
1x
W. Big Washer
2x
(For front axle inner side)
L
L
R
R
R
R
R
