3-8 Basic Operation PAS SERIES
Table 3-1 CONFIG settings
■ Descriptions of setting items
CV control (DEGIT A)
Select the constant voltage control f
ro
m panel control, external
voltage, external resistance, and external resistance (FAIL SAFE).
For details on external control, see "4.1 Analog Remote Control".
CC control (DEGIT B)
Select the constant current control
from panel co
ntrol, external
voltage, external resistance, and external resistance (FAIL SAFE).
For details on external control, see "4.1 Analog Remote Control".
Remote sensing (DEGIT C)
Set "0" to disable remote sensing, "1" to enable it.
F
or detail
s on remote sensing, see "3.6 Remote Sensing".
Voltmeter
DIGIT A DIGIT B DIGIT C DIGIT D
Preset
value
CV control CC control Remote
sensing
PWR ON
OUTPUT
0 Panel control Panel control OFF OFF at startup
1 External voltage
control
External voltage
control
ON ON at startup
2 External resistance
contro
l
10 kΩ → MAX OUT
Exte
rnal resistance
contro
l
10 kΩ → MAX OUT
3 E
xternal resistance
contro
l
10 kΩ → 0 OUT
(FA
IL SAFE)
External resistance
contro
l
10 kΩ → 0 OUT
(FAIL SAFE)
Ammeter
DIGIT E DIGIT F DIGIT G DIGIT H
Preset
value
Parallel/Series
master-slave
EXT OUTPUT
logic
TERMN during
digital remote
control
POWER switch trip
when the protection
circuit is activated
0 MASTER/LOCAL HIGH=ON OFF Enable(shutdown)
1 Parallel slave LOW=ON ON Disable(not shutdown)
2 Series slave
3
