PAS SERIES Basic Operation 3-9
PWR ON OUTPUT (DEGIT D)
Set "0" to start up the unit with the OUTPUT turned off when the
POWER sw
itch is turned on, "1" to start up the unit with the
OUTPUT turned on.
Master-slave series/parallel function (DEGIT E)
Set the master and slave units when using series or master-slave
paral
lel f
unction. Set "0" to make the unit a maser when the mas-
ter-control connection is made to the J1 connector.
Set "2" to make the unit a slave during series operation, "1" during
parallel operation.
For details on master-slave series/parallel operation, see Chapter5
"Parallel and Series Operation".
EXT OUTPUT logic (DEGIT F)
When controlling the on/off of the output through an external con-
tact (J1 conn
ecto
r), set "1" to turn on the OUTPUT with a low sig-
nal, "0" to turn on the OUTPUT with a high signal.
For details on the on/off control of the output using external con-
tacts, see "4.1.6 Controlling the Output ON/OFF Using External
Contact".
TERMN during digital remote control (DEGIT G)
When performing digital remote control, TERMN (termination) is
s
et on the unit at e
ach end of the bus.
For details on digital remote control, see "4.3 Digital Remote
Control".
POWER switch trip when the protection circuit is activated
(
DEGIT H)
Set "0" to trip (turn off) the POWER switch when OVP (overvolt-
age protection), OCP (overcurrent protection), or SHUT (shut-
down) is activated, "1" not to trip the POWER switch.
If set to "1" the OUTPUT is turned off when the above protection
circuits are activated.
• Precautions when setting PWR ON OUTPUT to "1"
To check the OVP operation, set the PWR ON OUTPUT to
"0" (off
at startup) first. Or, check the OVP operation first,
and then set PWR ON OUTPUT to "1" (on at startup).
If you check the OVP operation with PWR ON OUTPUT set
t
o "1
" (on at startup) when the POWER switch trip is set to
